Cubes Stone Splitting Machines

Cubes Stone Splitting Machines
These products could be widely applied in road construction, buildings & court yard structures, water & environment construction, such as piers, port facilities, river banks, water purification dams, flood area kerbs, docks, stone walls, noise barriers, embankments, counrtyard & park ornaments and paving stones.

Quantity:
  • Cubes Stone Splitting Machines
  • Bestlink

Multi Functional Laser Stone Splitting Machine


Hydraulic stone splitter, hydraulic stone splitting machine, which cut quarry leftover stone into any smaller natural face kerb stone, cube stone, wall stone, paveing stone etc. two kind of blade available, one is gear blade(cutting head), another is fluctating solid blade, both could adjust itself intelligently according the stone surface (height difference of stone surfaces within 4cm is recommended).



Thinking seriously about preparing another storage place for more and more leftover stone resulting from stone quarrying? Or how and where to discard the leftover stone fragment from stone slab processing?
Use our Bestlink stone machine, you may find a way resolve this problem partly. Our Bestlink stone machine could cut the quarry leftover stone into small cubes and crushed products or stamped factory slab leftover into different shapes of paving stone. These products could be widely applied in road construction, buildings & court yard structures, water & environment construction, such as piers, port facilities, river banks, water purification dams, flood area kerbs, docks, stone walls, noise barriers, embankments, counrtyard & park ornaments and paving stones.





StyleModelMax splittingSplitting
width×heightpressure
C-font styleBRT20T160×180mm20ton
BRT40T240×320mm40ton
BRT70T400×350mm70ton
BRT120T500×450mm120ton
BRT160T500×550mm160ton
Bridge styleBRT20T600×150mm20ton
BRT50T600×300mm50ton
BRT800T800×280mm80ton
BRT320T1200×800mm320ton



The line for stone splitting.from block to the correct size for mosaics,is designed for granite.This means that the line is suitable for all easily split types of rocks.By request we can prepare the project according to clients' conditions


Bestlink Factory

Xiamen Bestlink Factory Co., Ltd  is  committed  to  provide  the  best  drilling  and  cutting machine,  tools and accessories products in marble and granite stone quarrying,  as well as in civil engineering application, especial demolition project. it is now a leading manufacturer of cutting and drilling equipment for the extraction of marble, granite  and ornamental stones in china.
