Product advantages Features:
1. There is no need to purchase rock drilling rigs separately, which greatly saves costs.
2. Utilizing the crawling and rotating advantages of the excavator, it can work in severe working conditions with a wide operating range.
3. Unique oil circuit valve design, adjustable oil circuit distribution according to different working conditions to achieve the best rock drilling effect. The valve and electromagnetic reversing valve are all imported parts, which are precise, sturdy and durable.
4. The function of the excavator can be restored when not in use, and the existing resources can be fully utilized.
5. Low noise, low vibration, energy saving and high efficiency, low failure rate and high reliability;
6. Centralized operating mechanism, flexible start-up, convenient use and maintenance;
Product model | PD-Y28 |
Rock hardness | f=6-16 |
Size/mm | 3600×550×900 |
Drill pipe | H22-2500m |
single rod Drilling depth | 2200m |
Weight | 340kg |
Pneumatic Drifter | Y28 |
Drilling Diameter /mm | 30-42 |
Drifter Weight | 26kg |
Working pressure | 0.5-0.6MPa |
air consumption | 52-81L/s |
Impact power | 44-70J |
Impact frequency | 28-36Hz |
Rotation speed | 250-300r/min |
Drill speed | 250-470mm/min |
Noise | ≤125dB(A) |
Suitable Excavator | ≥4ton |
Hydraulic pressure | ≤16MPa |
